TASCAM DR-V1HD
9
1 – Introduction
Thank you very much for purchasing a TASCAM DR-V1HD HD Video/Linear
PCM Recorder.
Please read this Owner’s Manual carefully in order to maximize your use of all
the unit’s features. We hope that you will enjoy using this recorder for many
years to come. After you have finished reading this manual, please keep it in a
safe place for future reference.
You can also download this Owner’s Manual from the TASCAM website (http://
tascam.com/).
Features
Compact HD video and linear PCM recorder uses microSD/SDHC cards as •
recording media
Directional microphones enable high-quality stereo recording
•
Supports 1280 x 720p HD mode •
Camera lens and microphone can be rotated 180 degrees, enabling self- •
recording
1x to 4x digital zoom (in 0.1 increments)
•
Video, audio and photo modes •
Can take still pictures as a digital camera •
Linear PCM (WAV format) recording possible at 44.1, 48 or 96 kHz and 16 •
or 24-bit
HD video display on a TV possible using the mini-HDMI PORT (Type C)
•
2.4-inch 240x320 TFT Color LCD display •
Can show slide shows with 1-10 second intervals between still images •
Using the After Rec function, while playing back a recorded video file you •
can overwrite the playback sound with the input sound and record it as a
new file
Built-in 0.6W mono speaker
•
Allows monitoring througws recording (audio or video) to start •
automatically when the set audio input level is detected
When the 2GB maximum file size is reached, audio and video recording can
•
automatically continue in a new file without interruption
File incrementing and auto-recording functions can be used together to •
create new files when desired without interrupting recording (audio or
video)
Pre-recording function allows capture of up to 2 seconds of audio or video
•
before recording is activated manually
Automatic gain control function automatically adjusts input levels to make
•
recording levels as uniform as possible
Limiter function automatically reduces the input level suitably when it is
•
too high
Low cut filter function reduces low-frequency noise
•
VSA function changes playback speed from 50% to 150% (in 10% •
increments) of normal speed without changing pitch
Repeat playback and IN-OUT loop playback functions
•
Playlist function •
Auto power-off function can be set to 3, 5, 10 or 30 minutes, or OFF •
Divide function allows files to be split where desired •
File name format can be set to use a user-defined word or the date •
1/8" input jack for line input and external stereo microphones can provide •
plug-in power
1/8" line/headphones output jack
•
Mini-B type USB 2.0 port •
Operates on 3 AA batteries or a TASCAM PS-P520 AC adapter (sold •
separately)
Tripod attachment socket built into unit
•
