TASCAM HS-4000
113
11 – Internal settings
• After adding a file to a playlist from a different session
• After executing a REBUILD manually
• After executing a REBUILD from a pop-up message that
appears when a take or folder has been added or deleted by
FTP
REFERENCE LEVEL page
Set reference levels on this page.
Digital Ref. Level
Set the reference level for digital inputs and outputs to a
number of decibels below the maximum level (full scale).
Setting options: −9dB, −14dB, −16dB, −18dB, −20dB
(default)
Analog Input Ref. Lvl
Set the reference level for analog inputs.
The options differ according to the Digital Ref. Level setting.
Digital Ref. Level setting Analog Input Ref. Lvl
–9dB Fixed at +6dB
Not –9dB +4dB or –20dB
Analog Output Ref. Lvl
Set the reference level for analog line outputs.
The options differ according to the Digital Ref. Level setting.
Digital Ref. Level setting Analog Output Ref. Lvl
–9dB Fixed at +6dB
Not –9dB +4dB or –20dB
NOTE
Sound input through the analog audio inputs according
to the analog input reference level becomes sound in the
digital domain according to the digital reference level.
The analog audio outputs output digital sound according to
the digital reference level as analog sound according to the
analog output reference level.
ANA Ref LVL ADJ page
You can make fine adjustments to the analog input and output
reference levels independently for each channel.
Use an INX knob to adjust the analog input level of the corre-
sponding channel, and use an OUTX knob to adjust the analog
output level of the corresponding channel. (“X” is the channel
number.)
Touch a knob to select it, highlighting its area in yellow, and use
the DATA dial to adjust the level.
Turn the dial to adjust it in 0.1-dB intervals, and press and turn
the dial to adjust it in 1-dB intervals.
The value is shown beneath each knob.
Setting range: −6dB – +6dB (default: 0dB)
If an analog input for a channel is not set, the corresponding
knob will not be shown and Analog INX not selected will appear
in the menu area.
CH4 has no analog input
Backup/Startup page
Use this page to import and export system files, save and load
user settings and change the unit startup settings.
System Backup
0 Use the Export button to write all system backup data
(including user preset data) to the selected card.
0 Use the Import ALL button to write all system backup data
(including user preset data) from the selected card to the
built-in memory. This user preset data will immediately affect
how the unit operates.
0 Use the Import User button to write only the user preset data
from the system backup data on the selected card to the user
preset in the built-in memory. This user preset data does not
immediately affect how the unit operates. To make the user
