103
NV8500 Series
User’s Guide
For instructions on installing expansion output cards, see Installing I/O Cards on page 57. For
instructions on installing expansion backplanes, see Installing I/O Cards on page 57.
Expansion output cards are available for both standard and hybrid. The following is a list of all
expansion output cards and their corresponding backplanes:
Only coax backplanes (and cards) are used for hybrid I/O.
Signal Type Card Class Rates Signals Backplane
AES async: asynchro-
nous digital audio,
unbalanced and bal-
anced Standard Sample rates 32 to 192 kHz
(passed through)
9 AES pairs; 2
expansion EM0789
(coax)
EM0830
(WECO)
3Gig (coax): SD, HD, or
3Gig Standard Video rates from 19 Mb/s to
2.97 Gb/s.
Automatic reclocking at
270 Mb/s and 1.483, 1.485,
2.966, 2.970 Gb/s. Reclocking
bypassed at other rates.
Embedded audio passed
through
9 video; 2
expansion EM0789
(coax)
3Gig (fiber optic): SD,
HD, or 3Gig Standard 9 video; 2
expansion EM0698 (fiber
optic)
3Gig (coax): SD, HD, or
3Gig Hybrid Video rates from 19 Mb/s to
2.97 Gb/s.
Automatic reclocking at
270 Mb/s and 1.483, 1.485,
2.966, 2.970 Gb/s. Reclocking
bypassed at other rates.
Disembedded audio embed-
ded into video stream
8 video; 128
embedded
audio; 2 expan-
sion EM0789
(coax)
3Gig/TDM (coax): SD,
HD, or 3Gig with MADI Hybrid Video rates from 19 Mb/s to
2.97 Gb/s.
Automatic reclocking at
270 Mb/s and 1.483, 1.485,
2.966, 2.970 Gb/s. Reclocking
bypassed at other rates.
Embedded audio passed
through
Audio: 1 stream of 56 or 64
channels, 32 bits at 48 kHz,
locked to reference.
8 video; 1 MADI
stream; 2
expansion EM0789
Filler Either stan-
dard or hybrid
— 2 expansion
connectors
only EM0789
Note
Cable drivers are not present on output cards managing fiber optic signals.
