47
NV8500 Series
User’s Guide
These are the I/O cards for all routers except the NV8140:
Input Card Type Signals Remarks
Standard HD input 9 video Accepts HD or SD; coax
Standard 3Gig input 9 video Accepts 3Gig, HD, or SD; coax or fiber
AES async input 9 audio Accepts AES pairs; coax or twisted pair (STP)
Disembedder 8 video Accepts 3Gig, HD, or SD, coax only; can disembed 16
embedded audio channels for each video port
Frame sync
(disembedder)
8 video + 1 RJ-45 Accepts 3Gig, HD, or SD, coax only; can disembed 16
embedded audio channels for each video port. Addi-
tional RJ-45 port for configuring frame sync functions.
IP gateway,
(disembedder)
8 video Receives packetized video (via 10GE SFPs). Accepts 3Gig,
HD, or SD; 16 embedded audio channels for each video
stream; RJ-45 port for configuring IP functions.
3Gig/TDM input 8 video + 1 MADI Accepts 3Gig, HD, or SD and a MADI stream up to 64
channels; coax only
Output Card Type Signals Remarks
Standard HD output 18 video Accepts HD or SD; coax
Standard 3Gig output 18 video Accepts 3Gig, HD, or SD; coax or fiber
M3 18 video Accepts 3Gig, HD, or SD; M3 and coax
AES async output 18 audio Accepts AES pairs; coax or twisted pair (STP)
Embedder 16 video Accepts 3Gig, HD, or SD, coax only; can re-embed 16
audio channels for each video port
Disembedder/embedder 16 video Accepts 3Gig, HD, or SD, coax only; can re-embed 16
audio channels for each video port; special functions
IP gateway
(embedder)
8 video Transmits packetized video (via 10GE SFPs). Accepts 3Gig,
HD, or SD; 16 embedded audio channels for each video
stream; RJ-45 port for configuring IP functions.
3Gig/TDM output 16 video + 2 MADI Accepts 3Gig, HD, or SD and 2 MADI streams, 56 or 64
channels each; coax only
Expansion Output Card
Type
a
a. Applies only to the NV8576-Plus routers.
Signals Remarks
Standard HD output 9 video Transmits HD or SD; coax
Standard 3Gig output 9 video Transmits 3Gig, HD, or SD; coax or fiber
AES async output 9 audio Transmits AES pairs; coax or shielded twisted pair (STP)
Embedder 8 video Transmits 3Gig, HD, or SD, coax only; can re-embed 16
embedded audio channels for each video port
Disembedder/embedder 8 video Transmits 3Gig, HD, or SD, coax only; can re-embed 16
audio channels for each video port; special functions
3Gig/TDM output 8 video + 1 MADI Transmits 3Gig, HD, or SD and 1 MADI streams, 56 or 64
channels; coax only
