M3 Cards
M3 Backplane Module
Port Ordering
This drawing shows the port ordering — at the router — for an M3 backplane:
Fig. 12-1: M3 Port Numbering, at the Router
Port ordering at the KMX (multi-viewers) is different. See Figure 12-2, next page.
18
1
10
9
M3 OUT
18
1
10
9
M3 OUT
Right Side Up
(Upper Bay) Upside Down
(Lower Bay)
1–8
Video Ports
10–17
9
18
2–9
Video Ports
11–18
10
1
M3 Conn.
M3
Conn.
