38
Inputs and Outputs
Slot Numbering
This is the ordering of slots for output port numbering:
Fig. 2-6: NV8576 Slot Order for Output Port Numbering
NV8576-Plus
Port numbering for the NV8576-Plus follows the slot ordering shown in figures 2-7 and 2-8. An
NV8576-Plus has 64 output slots (32 upper and 32 lower) and 64 input slots (32 upper and 32
lower).
This is the ordering of slots for input port numbering, as viewed from the rear:
Fig. 2-7: NV8576-Plus Slot Order for Input Port Numbering
OUTPUTS
OUTPUTS
865–1008 577–720 289–432 1–144
1009–1152 721–864 433–576 145–288
INPUTS
INPUTS
(lower bay)
(upper bay)
Port Ranges
Port Ranges
63 61 60 59 58 57 64 62 47 45 44 43 42 41 48 46 31 29 28 27 26 25 32 30 15 13 12 11 10 9 16 14
55 53 52 51 50 49 56 54 39 37 36 35 34 33 40 38 23 21 20 19 18 17 24 22 7 5 4 3 2 1 8 6
Output Cards Output Cards Output Cards Output Cards
Output Cards Output Cards Output Cards Output Cards
23 21 20 19 18 17 24 22 7 5 4 3 2 1 8 6 15 13 12 11 10 9 16 14 31 29 28 27 26 25 32 30
63 61 60 59 58 57 64 62 47 45 44 43 42 41 48 46 55 53 52 51 50 49 56 54 39 37 36 35 34 33 40 38
INPUTS
INPUTS
Video Ports 289–432 Video Ports 1–144
Video Ports 433–576 Video Ports 145–288
(lower bay)
(upper bay)
63 61 60 59 58 57 64 62
47 45 44 43 42 41 48 46
31 29 28 27 26 25 32 30
15 13 12 11 10 9 16 14
55 53 52 51 50 49 56 54
39 37 36 35 34 33 40 38
23 21 20 19 18 17 24 22
7 5 4 3 2 1 8 6
Input Cards Input Cards Input Cards Input Cards
Input Cards Input Cards Input Cards Input Cards
47 45 44 43 42 41 48 46
15 13 12 11 10 9 16 14
39 37 36 35 34 33 40 38
7 5 4 3 2 1 8 6
63 61 60 59 58 57 64 62
31 29 28 27 26 25 32 30
55 53 52 51 50 49 56 54
23 21 20 19 18 17 24 22
