Grass Valley NV8500 Series v.3.5 - Manual (Page 231)

215
NV8500 Series
User’s Guide
Hybrid 3Gig disem-
bedder (coax):
SD, HD and 3Gig 8500H-IP-3G-
DEM-CX Hybrid Video rates from 19 Mb/s to
2.97 Gb/s.
(for cables listed, or equiva-
lent cables)
270 Mb/s,
400 m Belden 1694A,
250 m Belden 1855A
1.5 Gb/s
150 m Belden 1694A,
100 m Belden 1855A
3.0 Gb/s
100 m Belden 1694A,
45 m Belden 1855A
8, video;
128, audio EM0904
(coax)
Frame sync input
(coax): SD, HD and
3Gig 8500H-IP-3G-
FS-CX Hybrid Video rates from 19 Mb/s to
2.97 Gb/s.
(for cables listed, or equiva-
lent cables)
270 Mb/s,
400 m Belden 1694A,
250 m Belden 1855A
1.5 Gb/s
150 m Belden 1694A,
100 m Belden 1855A
3.0 Gb/s
100 m Belden 1694A,
45 m Belden 1855A
8, video;
128, audio;
Ethernet
(for config-
uration) EM0907
(coax +
RJ-45)
(for NV8140)
Hybrid 3Gig disem-
bedder (coax):
SD, HD and 3Gig
8140H-IP-3G-
DEM-CX Hybrid Video rates from 19 Mb/s to
2.97 Gb/s.
(for cables listed, or equiva-
lent cables)
270 Mb/s,
400 m Belden 1694A,
250 m Belden 1855A
1.5 Gb/s
150 m Belden 1694A,
100 m Belden 1855A
3.0 Gb/s
100 m Belden 1694A,
45 m Belden 1855A
16, video;
256, audio EM0888
(coax)
Card and Signal
Type
Part Number
Card
Class
Rates Signals
Back-
plane
