213
Part Numbers
This section provides a list of parts provided by Grass Valley for the NV8500 Series of routers, the
NV8300 power supply frame, and PS8300 power supply modules. Unless otherwise noted, part
numbers apply to all routers in the NV8500 Series.
Frames
The following is a list of frame part numbers for each router frame and each power supply frame:
Input Cards and Backplanes
The following is a list of all input cards and the corresponding backplanes:
Part Number Description
FR0045-03 NV8144 frame
FR0125-00 NV8140 frame
FR0044-03 NV8280 frame
FR0043-08 NV8576 frame
FR0073-06 NV8576-Plus frame
FR0034-01 NV8000 frame
a
a. Used in some existing systems
FR0111-00 NV8300 frame
Card and Signal
Type
Part Number
Card
Class
Rates Signals
Back-
plane
AES async (coax):
asynchronous digi-
tal audio, unbal-
anced 8500-AES-
ASYNC-IN Standard Sample rates 32 to 96 kHz
(passed through)
9, stereo EM0904
a
(coax)
AES async (WECO):
asynchronous digi-
tal audio, balanced 8500-AES-
ASYNC-IN Standard Sample rates 32 to 96 kHz
(passed through)
9, stereo EM0828
(WECO)
HD (coax):
SD or HD 8500-HD-IN-
COAX Standard 150m Belden 1694A, 85m
Belden 1855A, or equivalent
cable, at 1.5
Gb/s
9, video EM0904
(coax)
