372 Touch Probe Cycles: Automatic Workpiece Inspection
16.3 POLAR REFERENCE PLANE (Cy
c
le 1)
Cycle parameters
U Probing axis: Enter the probing axis with the axis
selection keys or ASCII keyboard. Confirm your entry
with the ENT key. Input range: X, Y or Z
U Probing angle: Angle, measured from the probing
axis, at which the touch probe is to move. Input range
–180.0000 to 180.0000
U Nominal position value: Use the axis selection keys
or the ASCII keyboard to enter all coordinates of the
nominal pre-positioning point values for the touch
probe. Input range –99999.9999 to 99999.9999
U To conclude the input, press the ENT key.
Example: NC blocks
67 TCH PROBE 1.0 POLAR REFERENCE PLANE
68 TCH PROBE 1.1 X ANGLE: +30
69 TCH PROBE 1.2 X+5 Y+0 Z-5
