Reference MVI46-103M ♦ SLC Platform
IEC 60870-5-103 Master Communication Module
ProSoft Technology, Inc. Page 125 of 187
September 12, 2006
# Database definition for this session/sector
#
# ASDU Database Function Point
# Type Index Code Index
START
END
[IEC-103 Master Session 16 Sector 3]
Common ASDU Address : 3 #Range 0 to 65534 Sector address
#Req init requests when session first online (not req if slave sends
# EOI sequence)
Online Time sync : Y #Send time sync message when first online
Online General Int : Y #Send general interrogation
#Req init requests when EOI (end of initialization) received from slave
EOI Time sync : Y #Send time sync message when first online
EOI General Int : Y #Send general interrogation
# Database definition for this session/sector
#
# ASDU Database Function Point
# Type Index Code Index
START
END
[IEC-103 Master Session 16 Sector 4]
Common ASDU Address : 4 #Range 0 to 65534 Sector address
#Req init requests when session first online (not req if slave sends
# EOI sequence)
Online Time sync : Y #Send time sync message when first online
Online General Int : Y #Send general interrogation
#Req init requests when EOI (end of initialization) received from slave
EOI Time sync : Y #Send time sync message when first online
EOI General Int : Y #Send general interrogation
# Database definition for this session/sector
#
# ASDU Database Function Point
# Type Index Code Index
START
END
# This section is used to define session 0 which runs on Port 1
[IEC-103 Master Session 17]
Communication Port : 0 #Index of COM port for session (0 or 1)
Sector Count : 5 #1 is max value for this version of app
Data Link Address : 17 #Range is 0 to 65535 DL address of slave
Failure Delay : 10 #Min Sec to delay before poll of offline slave
#(0 to 2000 seconds)
Confirm Timeout : 1000 #0 to 2^32-1 mSec to wait for DL confirm
Retry Count : 2 #0 to 255 retries for if no confirm
