COT Description
31 transmission of disturbance data
40 generic write command
42 generic read command
7.8.3 List of Function Types
Fun Description SYMBOL
128 Distance protection t(z)
160 Overcurrent protection l>>
176 Transformer differential protection ∆l
T
192 Line differential protection ∆l
L
254 Generic function type GEN
255 Global function type GLB
7.8.4 Information Numbers Used In Monitor Direction
System functions
Fun
128 160 176 192 254 255
Inf Description GI Type
t(z) l>> ∆l
T
∆l
L
GEN GLB
0 end of general interrogation 8 X
0 time synchronization 6 X
2 reset FCB 5 *
3 reset CU 5 *
4 start/restart 5 *
5 power on 5 *
* - According to main function
Status Indications
Fun
128 160 176 192 254 255
Inf Description GI Type
t(z) l>> ∆l
T
∆l
L
GEN GLB
16 auto-recloser active X 1 X X X
17 teleprotection active X 1 X X
18 protection active X 1 X X X X
19 LED reset 1 X X X X
