4 From the Transfer menu in HyperTerminal, select Send File.
The Send File dialog appears.
5 Use the Browse button to locate the configuration file your computer.
Note: This procedure assumes that you are uploading a newly edited
configuration file from your PC to the module. However, configuration files are
also available on the ProSoft CD as well as the ProSoft Technology web site at
http://www.prosoft-technology.com.
6 Select Ymodem as the protocol.
