Functional Overview

MVI46-103M ♦ SLC Platform

IEC 60870-5-103 Master Communication Module

ProSoft Technology, Inc.

Page 19 of 187

September 12, 2006

As shown in the table above, all bit types are addressed as bits in the modules
database.

Addressing the Data Types

The following table shows an example of how to address the data types in the
MVI46-103M:

Data Type

Address Type

Length

Example

1 Bit 2

bits

Address 160 refers to first and second bits from
word 10.

2 Bit 2

bits

Address 160 refers to first and second bits from
word 10.

3

Word

4 words

Address 50 refers to word 50, 51, 52, and 53.

4 Double-word

2

words

Address 40 refers to two consecutive words
starting at word 80.

5 Bit 12

bits

Address 180 refers to 12 consecutive bits
starting at the LSB of word 90.

9 Word 5

words

Address 100 refers to 9 consecutive words
starting at word 100.

20 Bit

2

bits

Address 160 refers to the first and second bits
from word 10.

Therefore, address 16000 represents bit zero in word 1000 of the module's
database. Short floating-point, 32-bit strings and integrated total values each
occupy a double-word space in the database. Therefore, short float database
address of 100 represents the two words, 200 and 201, in the modules database.
Identification objects are stored as byte values in the modules database.
Identification object address 1000 is stored in the module's database in word
addresses 500 to 505.

When setting the monitored data and commands, each point is defined by its
ASDU type, function code, and information number. Valid function codes are
listed in the following table:

Function Code

Symbol

Number

Distance Protection

T(z)

128

Over-current Protection

I>>

160

Transformer Differential
Protection

rIt 176

Line Differential Protection

rIl

192

Global Function Type

GLB

255

Refer to Protocol Interoperability Documentation for a full listing of the protocol
support offered by the module.

Ladder logic in the SLC can control the module or devices on the serial network
using special control blocks. The following table lists the special control codes
(block numbers) used by the module:
