MVI46-103M ♦ SLC Platform Diagnostics and Troubleshooting
IEC 60870-5-103 Master Communication Module
Page 54 of 187 ProSoft Technology, Inc.
September 12, 2006
6.4.2 Database View Menu
Press [D] from the Main Menu to open the Database View menu. Use this menu
command to view the current contents of the module's database. Press [?] to
view a list of commands available on this menu.
Viewing Database Pages 0 to 3000
The database is divided into pages that correspond with a specific number of
registers. The total number of database pages and registers depends on the
memory capacity and configuration of the module.
Use the keyboard commands [0] through [3] to display database contents
starting from 0 (zero), 1000, 2000 and 3000 respectively.
Moving Back Through 5 Pages of Registers
Press [-] from the Database View menu to skip back to the previous 500
registers of data.
Viewing the Previous 100 Registers of Data
Press [P] from the Database View menu to display the previous 100 registers of
data.
