Reference MVI46-103M ♦ SLC Platform
IEC 60870-5-103 Master Communication Module
ProSoft Technology, Inc. Page 165 of 187
September 12, 2006
Fun
128 160 176 192 254 255
Inf Description GI Type
t(z) l>> ∆l
T
∆l
L
GEN GLB
20 monitor direction blocked X 1 X X X X
21 test mode X 1 X X X X
22 local parameter setting X 1 X X X X
23 characteristic 1 X 1 X
24 characteristic 2 X 1 X
25 characteristic 3 X 1 X
26 characteristic 4 X 1 X
27 auxiliary input 1 X 1 X X X X
28 auxiliary input 2 X 1 X X X X
29 auxiliary input 3 X 1 X X X X
30 auxiliary input 4 X 1 X X X X
Supervision indications
Fun
128 160 176 192 254 255
Inf Description GI Type
t(z) l>> ∆l
T
∆l
L
GEN GLB
32 measured supervision I X 1 X X
33 measured supervision V X 1 X X
35 phase sequence supervision X 1 X X
36 trip circuit supervision X 1 X X X X
37 l>>back-up operation X 1 X
38 VT fuse failure X 1 X X
39 teleprotection disturbed X 1 X X X
46 group warning X 1 X X X X
47 group alarm X 1 X X X X
Earth fault indications
Fun
128 160 176 192 254 255
Inf Description GI Type
t(z) l>> ∆l
T
∆l
L
GEN GLB
48 earth fault L
1
X 1 X X
49 earth fault L
2
X 1 X X
50 earth fault L
3
X 1 X X
51 earth fault forward (that is, line) X 1 X X
52 earth fault reverse (that is, busbar) X 1 X X
