MVI46-103M ♦ SLC Platform Reference
IEC 60870-5-103 Master Communication Module
Page 174 of 187 ProSoft Technology, Inc.
September 12, 2006
7.9.4 Transmission speed
⌧ 9 600 bit/s
⌧ 19 200 bit/s
7.9.5 Link Layer
There are no choices for the link layer.
7.9.6 Application Layer
7.9.7 Transmission mode for application data
Mode 1 (least significant octet first), as defined in 4.10 of IEC 60870-5-4, is used
exclusively in this companion standard.
7.9.8 Common address of ASDU
⌧ One Common Address of ASDU (identical with station address)
⌧ More than one Common Address of ASDU
7.9.9 Selection of standard information numbers in
monitor direction
7.9.10 System functions in monitor direction
INF Semantics
⌧ <0> End of general interrogation
⌧ <0> Time synchronization
⌧ <2> Reset FCB
⌧ <3> Reset CU
⌧ <4> Start/restart
⌧ <5> Power on
7.9.11 Status indications in monitor direction
INF Semantics
⌧ <16> Auto-recloser active
