ProSoft Technology MVI46-103M - Manual (Page 178)

MVI46-103M ♦ SLC Platform Reference
IEC 60870-5-103 Master Communication Module
Page 178 of 187 ProSoft Technology, Inc.
September 12, 2006
<240> Read headings of all defined groups
<241> Read values or attributes of all entries of one group
<243> Read directory of a single entry
<244> Read value or attribute of a single entry
<245> End of general interrogation of generic data
<249> Write entry with confirmation
<250> Write entry with execution
<251> Write entry aborted
7.9.18 Selection of standard information numbers in control
direction
7.9.19 System functions in control direction
INF Semantics
⌧ <0> Initiation of general interrogation
⌧ <0> Time synchronization
7.9.20 General commands in control direction
INF Semantics
⌧ <16> Auto-recloser on/off
⌧ <17> Teleprotection on/off
⌧ <18> Protection on/off
⌧ <19> LED reset
⌧ <23> Activate characteristic 1
⌧ <24> Activate characteristic 2
⌧ <25> Activate characteristic 3
⌧ <26> Activate characteristic 4
7.9.21 Generic functions in control direction
INF Semantics
