Reference MVI46-103M ♦ SLC Platform
IEC 60870-5-103 Master Communication Module
ProSoft Technology, Inc. Page 97 of 187
September 12, 2006
C1/C2 Poll Count Pend : 0 #class 1 or 2 polls before next slave tried (0-
65535)
Class 1 Polls : 0 #Max class 1 polls to this session
Class 1 Pend delay : 0 #Min mSec delay between call (0 to 2^32-1)
Class 2 Pend delay : 0 #Min mSec delay between call (0 to 2^32-1)
Class 1 Poll delay : 0 #Min mSec delay between call (0 to 2^32-1)
Class 2 Poll delay : 0 #Min mSec delay between call (0 to 2^32-1)
[IEC-103 Master Session 3 Sector 0]
Common ASDU Address : 0 #Range 0 to 65534 Sector address
#Req init requests when session first online (not req if slave sends
# EOI sequence)
Online Time sync : Y #Send time sync message when first online
Online General Int : Y #Send general interrogation
#Req init requests when EOI (end of initialization) received from slave
EOI Time sync : Y #Send time sync message when first online
EOI General Int : Y #Send general interrogation
# Database definition for this session/sector
#
# ASDU Database Function Point
# Type Index Code Index
START
END
[IEC-103 Master Session 3 Sector 1]
Common ASDU Address : 1 #Range 0 to 65534 Sector address
#Req init requests when session first online (not req if slave sends
# EOI sequence)
Online Time sync : Y #Send time sync message when first online
Online General Int : Y #Send general interrogation
#Req init requests when EOI (end of initialization) received from slave
EOI Time sync : Y #Send time sync message when first online
EOI General Int : Y #Send general interrogation
# Database definition for this session/sector
#
# ASDU Database Function Point
# Type Index Code Index
START
END
[IEC-103 Master Session 3 Sector 2]
Common ASDU Address : 2 #Range 0 to 65534 Sector address
#Req init requests when session first online (not req if slave sends
# EOI sequence)
Online Time sync : Y #Send time sync message when first online
Online General Int : Y #Send general interrogation
#Req init requests when EOI (end of initialization) received from slave
