Chapter 2 Object Design
Document No: 2.3.004 Revision: 2.0 Updated: 3/21/2012
Setting the Background
Applying Images on
the Background
CG pages are designed using many objects, including a background. The background can be animated to be applied as part of the
page, left transparent to show live video, or a still image as a traditional background.
Turn On/Off the Background using the [Show Background] button.
Applying Color on the
Background
Click on the Page tab in [Attribute]
or double-click on the Edit Window
to activate the Page tab. Click on
the [Mix Color] button in [Color
Palette] > [Texture]. Select a color
from [Color] or [Swatch]. Click on
the [Show Background] button in
[Attribute] > [Page].
Right-click on the edit window to
open the context menu. Select [Set
Background Image] and choose an
image to apply. Click on the [Show
Background] button in [Attribute] >
[Page] > [Background] to show the
image.
Background Activated
Tip
Even if the background image has
been inserted, if the [Show Back-
ground] button is inactive, the back-
ground will not go on-air.
Background Deactivated
Tip
Check to be sure that the Select Tool
on the toolbar is active before
opening a background image. If
another tool is selected, the image may
not appear.
