Page 88 - Pointmaker PVI-65 HD/SD-SDI Broadcast Video Marker Boeckeler Instruments, Inc.
Commands Section Six: Commands for RS-232 Control
(EM) Erase Method
The “EM” command activates your choice of erase methods.
(FS) Frame Size
The “FS” command defines an active frame.
(FT) Frame Type
The “FT” command tells the Pointmaker which type of frame to display on-
screen.
(I) Marker Intensity or Brightness
The “I” command sets the intensity or brightness level for markers. Positive or
negative values may be coded.
ESC(EM0 Erase Method: "UNDO"
ESC(EM1 Erase using Small eraser
ESC(EM2 Erase using Medium eraser
ESC(EM3 Erase using Large eraser
<Esc>(FSXXXXYYYY Designating the size of an active frame.
XXXX = a numeric value for the horizontal
dimension. YYYY = a numeric value for the
vertical dimension. Units range from ØØØ1 to
1Ø24.
<Esc>(FTBØ Box Frame
<Esc>(FTB1 Filled Box Frame
<Esc>(FTCØ Circle Frame
<Esc>(FTC1 Filled Circle Frame
<Esc>(FTN Next Frame
<Esc>(ISXXX Set the brightness level (absolute). XXX is numeric value
between -256 and 256.
