14 Tables and Overviews
228
1
4
.3
T
ec
hnical
Inf
o
rmation
Programmable functions
Contour elements
n
Straight line
nÿ
Chamfer
n
Circular arc
n
Circle center
n
Circle radius
n
Tangentially connecting circle
n
Corner rounding
n
Straight lines and circular arcs for contour approach and departure
Program jumps
n
Subprograms
n
Program section repeats
Fixed cycles
n
Drilling cycles for drilling, pecking, reaming, boring
back boring, tapping with a floating tap holder
n
Roughing and finishing rectangular and circular pockets
nÿ
Cycles for milling linear and circular slots
n
Linear and circular hole patterns
n
Cycles for multipass milling of flat and irregular surfaces
Coordinate transformations
n
Datum shift
n
Mirroring
nÿ
Rotation
n
Scaling
3-D touch probe applications
n
Touch probe functions for setting the datum
TNC Specifications
Block processing time
40 ms/block
Control loop cycle time
Contouring interpolation: 6 ms
Data transfer rate
Maximum 115 200 baud
Ambient temperature
n
In operation: 0°C to +45°C
n
Storage: –30°C to +70°C
Traverse range
Maximum 30 m (1181 inches)
Traversing speed
Maximum 30 m/min (1181 inches/min)
Spindle speed
Maximum 30 000 rpm
Input range
n
Minimum 1µm (0.0001 inches) or 0.001°
n
Maximum 30 000 mm (1 181 inches) or 30 000°
