User's manual K&F SEQUENZA 5 incl. accessories
KLING & FREITAG GMBH © 2015 Version 4.1 Page 22 of 88
1. Place the speaker, flying
frame or adapter onto a
standing speaker so that the
joint bars are next to one
another.
2. Ensure that the safety latch
of the standing speaker is
pushed into the enclosure
by the joint bars of the
adjoining device.
3. Push the speaker to the side
to allow the joint bars to
connect properly and ensure
that the safety latch of the
joint snaps into place.
4. The safety latch makes a
clearly audible clicking noise
when snapping into place.
Warning
Make sure that the joint
bolts in both joints are
properly connected in the
joint bar.
Make sure the red dot is
visible on the safety latch,
indicating a properly
locked joint.
