User's manual K&F SEQUENZA 5 incl. accessories
KLING & FREITAG GMBH © 2015 Version 4.1 Page 37 of 88
9.3.5 Mounting SEQUENZA 5 W to SEQUENZA 5 Flying Frame,
Flown
When mounting a SEQUENZA 5 W
speaker with a SEQUENZA 5 flying frame,
you must use the flying frame connector
that is provided with the flying frame.
Upon delivery of the flying frame, the
flying frame connector is secured in its
park position with a ball lock pin.
Tip
To ensure that the flying frame
connector is available at all times
and cannot get lost, we recommend
fastening it back into its park position
on the flying frame when not in use.
For the flying mode, you can mount a complete triple from a transport case in one step.
Tip
You can also mount the triples directly from vertically standing transport cases. This
procedure is especially recommendable when you have little room for assembly.
If you also disassemble the speakers using a vertically standing transport case, you can be
certain that the speakers are in the transport case the right way for the next assembly.
1. Prepare the flying frame for flying mode. (see chap. 'Preparing the SEQUENZA 5
Flying Frame, Flown' on page 30)
2. Open the transport case of the SEQUENZA 5 W triple by turning the catches 180°
and removing the lid.
3. Connect the SEQUENZA 5
flying frame with the
SEQUENZA 5 W speaker as
explained in chapter '[...]' on
page 21.
