User's manual K&F SEQUENZA 5 incl. accessories
KLING & FREITAG GMBH © 2015 Version 4.1 Page 40 of 88
3. Fold the connector between
the connecting plates of the
adjacent speaker.
Secure the connection with
the ball lock pin.
4. The speaker is now completely assembled and secured.
If you don't want to mount any more speakers, then you can now wire the speakers.
Further information in chapter 'Wiring' on page 65.
Detailed information for connecting the speakers and configuring the K&F system amplifier
TOPAS or the K&F SystemRack is in the hardware manuals.
9.3.7 Mounting SEQUENZA 5 W to SEQUENZA 5 W, Flown
When mounting a SEQUENZA 5 W
speaker with another SEQUENZA 5 W
speaker, you must use the provided
connector on the speaker.
Tip
If you also disassemble the speakers using a vertically standing transport case, you can be
certain that the speakers are in the transport case the right way for the next assembly.
