User's manual K&F SEQUENZA 5 incl. accessories
KLING & FREITAG GMBH © 2015 Version 4.1 Page 47 of 88
2. Make sure you can see the
red dot on the safety latch.
Use a ball lock pin to fasten
the connector of the adapter
in the desired drill hole on
the speaker.
3. Lower the SEQUENZA 10 N/
W array until you can insert
the downfill adapter into
the lower speaker.
Secure the connection with
one ball lock pin on each
side.
4. Lift the speaker and connect
the upper connector bracket
in the 1° angle drill hole
with the SEUQNZA 10
speaker.
Secure the connection with
the ball joint pin.
5. If further speakers are to
be flown, connect them as
described on page 21.
If you don't want to mount any more speakers, then you can now wire the speakers.
Further information in chapter 'Wiring' on page 65.
