26
Fuel Point PLUS Station Equipment Manual
Parameter
Value
PHYSICAL
Height
180 mm (7.087")
Width
182 mm (7.165")
Depth
62.5 mm (2.461")
Weight
0.86 Kg
ELECTRICAL
Operating voltage
12 - 28 VDC
Operating current
0.5 A
ENVIRONMENTAL
Operating temperature
-40°C to +55°C (-40°F to +131°F)
Humidity
95% RH
COMMUNICATION
TCP/IP over Ethernet
EIA 802.15.4
2.405- 2.480 GHz ISM band RF Network Communication with AES128 encryption
POWER SUPPLY
DC output voltage
12 - 28 VDC
Rated current
0.35 A
Current range
0~0.625 A
Rated power
15 W
Voltage tolerance
1.0%
Line regulation
0.5%
Load regulation
0.5%
Input voltage range
85~264 VAC
Frequency range
47~63 Hz
AC current (typical)
0.35 A/115 VAC 0.25 A/230 VAC
Table 2-1 - Wireless Gateway Outdoor Compact Box - Integrated P/S
Specifications
