Fuel Point PLUS Station Equipment Manual 65
Figure 6-17 - Log Level
1. In the In the Debug Port Interface drop-down, select TCP/IP . The Debug Port field is auto-
populated with default port: 5000 . There is no need to change this port
2. Choose which logs you want to collect and the level of detail, by selecting the checkboxes in the
row of the log source (see
Table 6-9 ):
Data : Only data sent
Debug : Additional debug info
3. Select the logging level:
Info : Detailed logs
Error : Error logs only
4. Click Submit
Example:
The system keeps logs from all sources at error level, as a default. You may want to get
detailed data on VIT (Communication between Wireless Gateway and WNR) and on VIU
(Data on vehicle units received during refueling).
To do so, select Data, Debug and Info in both VIT and VIU rows.
Note: Log Events (Flash) section is currently not available.
