Fuel Point PLUS Station Equipment Manual 27
2.3.1.2. Wireless Gateway Outdoor Compact Box Specifications
(See Table 2-2 )
Parameter Value
PHYSICAL
Height 180 mm (7.087")
Width 182 mm (7.165")
Depth 62.5 mm (2.461")
Weight 0.73 Kg
ELECTRICAL
Operating voltage 12 - 28 VDC
Operating current 0.5 A
ENVIRONMENTAL
Operating temperature -40°C to +55°C (-40°F to +131°F)
Humidity 95% RH
COMMUNICATION
TCP/IP over Ethernet
EIA 802.15.4
2.405- 2.480 GHz ISM band RF Network Communication with AES128 encryption
Table 2-2 - Wireless Gateway Outdoor Compact Box Specifications
2.3.2. Wireless Gateway Outdoor
Outdoor box (see Figure 2-3 ) specially designed for:
Installation on top of the pumps/dispensers
Installation in the station's office, C-Store
Prepared for wall-mounting
Includes optional integrated power supply
