HDMI control function
If the HDMI control function does not operate properly, check the
following points.
• Is the TV or player compatible with the HDMI control function?
• Is “HDMI Control” (
) set to “On”?
• Is “Power Off Control” (
) set for the monitor output
connected to television?
) set to the TV that uses the
HDMI control function when this unit is connected to two TVs that
support HDMI connectors?
• Are the HDMI control function settings of all devices correct?
NOTE
• When “HDMI Control” is set to “On”, it consumes more standby
power.
• The HDMI control function controls operations of a TV that is
compatible with the HDMI control function. Make sure that the TV
and HDMI are connected when you perform HDMI control.
• Some functions may not operate depending on the connected TV
or player. Check the owner’s manual of each device for details
beforehand.
• When “Power Off Control” on the menu is set to “Off”
), this unit is not set to standby even if the connected
device is in the standby mode.
• When connection changes are implemented, such as adding
connections to HDMI devices, linked operations may be initialized.
In this case, you will need to reconfigure the settings.
• When “HDMI Control” is set to “On”, it is not possible to assign an
HDMI connector to “TV AUDIO” at “Input Assign” (
).
• Should any of the operations below be performed, the interlocking
function may be reset, in which case, repeat steps 2 and 3.
• “Input Assign” – “HDMI” (
• “Video Output” (
• There is a change to the connection between the devices and the
HDMI, or an increase in devices.
• The HDMI ZONE4 function is compatible with the HDMI control
function.
• The ARC function, Power Off Control function, and Volume Control
function is not compatible with the HDMI ZONE4 control function.
• When the HDMI ZONE4 function is used with “HDMI Control” in
the menu set to “On”, the HDMI ZONE4 control function may not
fully work.
• When the power in ZONE4 is on with “HDMI Control” (
)
set to “On” and “Control Monitor” set to “Monitor 1” or “Monitor
2” (
), the following operations occur (Some example
behaviors are listed below.).
• When the power of the TV used for MAIN ZONE is off and the
player selected for ZONE4 starts playback, the TV used for MAIN
ZONE is turned on. In this case, the input source selected for MAIN
ZONE changes to the input source selected for ZONE4.
• When playing back a TV used for MAIN ZONE and ZONE4 with
an HDMI connection, turning off the TV used for MAIN ZONE also
turns off this unit and the player.
• When a same input source is selected for MAIN ZONE and ZONE4,
stopping playback of the player on the TV stops the playback on the
player and the video being played back in ZONE4 as well.
• When the power in ZONE4 is on with “HDMI Control” (
)
set to “On” and “Control Monitor” set to “ZONE4” (
the following operations occur.
• When the power of the TV used for ZONE4 is off and the player
selected for MAIN ZONE starts playback, the TV used for ZONE4
is turned on. In this case, the input source selected for ZONE4
changes to the input source selected for MAIN ZONE.
• When playing back a TV used for ZONE4 and MAIN ZONE with an
HDMI connection, turning off the TV used for ZONE4 also turns
off the player.
• When a same input source is selected for ZONE4 and MAIN ZONE,
stopping playback of the player on the TV stops the playback on
the player and the video being played back in MAIN ZONE as well.
