The unit automatically enters “medium, Mode, Dynamic eq – Marantz AV8801 User Manual
Page 127: Dynamic volume, Tone control” can be set when “dynamic eq, Is set
124
Audio
Setting items
Setting details
Dynamic EQ
Solve the problem of
deteriorating sound quality
as volume is decreased
by taking into account
human perception and
room acoustics. Works with
MultEQ® XT 32.
On : Use Dynamic EQ.
Off : Do not use Dynamic EQ.
•
is displayed when set to “On”.
• This can also be set by pressing
DYNAMIC EQ
on the main unit.
Each time
DYNAMIC EQ
is pressed, the setting is changed as shown
below.
On
Off
NOTE
When the menu “Dynamic EQ” setting is “On”, it is not possible to do
“Tone Control” (
Reference Level Offset
Audyssey Dynamic EQ® is
referenced to the standard
film mix level. It makes
adjustments to maintain
the reference response
and surround envelopment
when the volume is turned
down from 0 dB. However,
film reference level is not
always used in music or
other non-film content.
Dynamic EQ Reference
Level Offset provides three
offsets from the film level
reference (5 dB, 10 dB, and
15 dB) that can be selected
when the mix level of the
content is not within the
standard. Recommended
setting levels are shown at
right.
0dB (Film Ref) : This is the default setting and should be used when
listening to movies.
5dB : Select this setting for content that has a very wide dynamic range,
such as classical music.
10dB : Select this setting for jazz or other music that has a wider dynamic
range. This setting should also be selected for TV content as that is usually
mixed at 10 dB below film reference.
15dB : Select this setting for pop/rock music or other program material
that is mixed at very high listening levels and has a compressed dynamic
range.
Setting is enabled when “Dynamic EQ” is “On” (
Setting items
Setting details
Dynamic Volume
Solve the problem of large
variations in volume level
between TV, movies and
other content (between
quiet passages and
loud passages, etc.) by
automatically adjusting to
the user’s preferred volume
setting.
Heavy : Most adjustment to softest and loudest sounds.
Medium : Medium adjustment to loudest and softest sound.
Light : Least adjustment to loudest and softest sounds.
Off : Do not use “Dynamic Volume”.
•
is displayed when set to “Heavy”, “Medium” or “Light”.
• If “Dynamic Volume” is set to “Yes” in “Audyssey® Setup”
), the setting is automatically changed to “Medium”.
• This can also be set by pressing
DYNAMIC VOL
on the main unit.
Each time
DYNAMIC VOL
is pressed, the setting is changed as shown
below.
Off
Heavy
Medium
Light
Audyssey LFC™
Adjusts the low frequency
band to prevent bass
and vibration from being
conveyed to neighboring
rooms.
On : Use “Audyssey LFC™”.
Off : Do not use “Audyssey LFC™”.
“Audyssey LFC™” cannot be set up if “Audyssey® Setup” is not
completed.
About Audyssey LFC™ (Low Frequency Containment)
Audyssey LFC™ solves the problem of low frequency sounds
disturbing people in neighboring rooms or apartments. Audyssey
LFC™ dynamically monitors the audio content and removes the low
frequencies that pass through walls, floors and ceilings. It then applies
psychoacoustic processing to restore the perception of low bass for
listeners in the room. The result is great sound that no longer disturbs
the neighbors.
Containment Amount
Adjusts the amount of low
frequency containment. Use
higher settings if you have
close neighbors.
1 – 7 (4)
