Marantz AV8801 - Manual (Page 185)

182
Symptom Cause/Solution Page
When the HDMI
ZONE4 function is
used, no video or
audio is output to TV
in ZONE4. • Make sure that the power is on for ZONE4.
• Check the input source for ZONE4.
• Check the output settings (resolution/audio format) for the input
device.
• The HDMI 7 / MHL connector on the front panel does not support
the HDMI ZONE4 function.
• For ZONE4, playback is only possible when the input signals are
HDMI signals.
113
113
–
–
–
When playing back
the input device just
to use the HDMI
ZONE4 function, the
TV used for MAIN
ZONE is turned on. • “HDMI Control” in the menu is set to “On”. When using the
HDMI ZONE4 function, set “HDMI Control” in the menu to “Off”.
102 , 128
GVideoH
Symptom Cause/Solution Page
No picture appears. • Check the connection between the video output terminal of this
unit and the input terminal of the TV.
• Match the input settings to the input terminal of the TV connected
to this unit.
11 , 17
–
GAudioH
Symptom Cause/Solution Page
Audio is not output. • Check the connections for all devices.
• Check the speaker connections and configurations.
• Check the connections for PRE OUT terminals.
• Check whether the audio device power is turned on.
• Adjust the master volume.
• Cancel the mute mode.
• Check the connection with the playback device and select the
proper input source.
• Match the input mode and the terminal assigned to be the digital
input terminal.
• Disconnect the headphones. No sound is output from the PRE
OUT terminals when headphones are connected.
11 , 12 , 17 , 18 ,
19 , 20 , 21 , 22 ,
23 , 24 , 26 , 27 ,
28 , 29 , 30 , 31 ,
33
31 , 95 , 96 , 97
31 , 95 , 96 , 97
–
44 , 113
44 , 113
43 , 113
136
162
The volume does not
increase. • The maximum volume is set too low. Set the maximum volume
using “Limit”on the menu.
• Power for external devices connected to the output connectors
of the unit may not be turned on. Check the power of connected
external devices.
123
–
No sound is
produced from
surround speaker. • Check if the surround speakers are connected to the SURROUND
terminals of power amplifire.
–
No sound is
produced from
surround back
speaker. • Set “Speaker Config.” – “Surr. Back” on the menu to something
other than “None”.
• Set the sound mode to something other than “STEREO” and
“VIRTUAL”.
138
86
No sound is
produced from front
height speaker. • Set “Speaker Config.” – “Front Height” on the menu to something
other than “None”.
138
No sound is
produced from front
wide speaker. • Set “Speaker Config.” – “Front Wide” on the menu to something
other than “None”.
138
