122
M-DAX
Compressed audio formats such as MP3, WMA (Windows Media Audio) and MPEG-4 AAC reduce the
amount of data by eliminating signal components that are hard for the human ear to hear. The M-DAX
function generates the signals eliminated upon compression, restoring the sound to conditions near those
of the original sound before compression. It also corrects the sense of volume of the bass to obtain richer
sound with compressed audio signals.
Setting items Setting details
Mode
Set the mode for M-DAX. Off : Do not use M-DAX.
Low : Optimized mode for compressed sources with normal highs.
Mid : Apply suitable bass and treble boost for all compressed sources.
High : Optimized mode for compressed sources with very weak highs.
• This item can be set with analog signals or PCM signal (Sample rate =
44.1/48 kHz) is input.
• “M-DAX” settings are stored for each input source.
• When set to “Off”, the M-DAX indicator on the front panel switches off.
• This cannot be set when the surround mode is set to “DIRECT” or
“PURE DIRECT”.
• This can also be set by pressing M-DAX on the main unit.
Each time M-DAX is pressed, the setting is changed as shown below.
Off Low
Mid High
Audio Delay
Default settings are underlined.
While viewing video, manually adjust the time to delay audio output.
Setting details
0ms – 200ms
• This item can be set within the range of 0 to 100 ms when “Auto Lip Sync” ( vpage 127 ) is set to
“On” and when a TV compatible with Auto Lip Sync is connected.
• Store “Audio Delay” for each input source.
• Audio Delay for game mode can be set when “Video Mode” (
vpage 129 ) is set to “Auto” or
“Game”.
Audio
Tone
Default settings are underlined.
Adjust the tonal quality of the sound.
Setting items Setting details
Tone Control
Set the tone control function
to “On” and “Off”. On : Allow tone adjustment (bass, treble).
Off : Playback without tone adjustment.
“Tone Control” can be set when “Dynamic EQ” ( vpage 124 ) is set
to “Off”.
NOTE
• “Tone Control” settings are not reflected to ZONE2 and ZONE3.
• The tone cannot be adjusted in the “DIRECT” and “PURE DIRECT”
mode.
Bass
Adjust bass. –6dB – +6dB (0dB)
“Bass” can be set when the menu “Tone Control” setting is “On”.
Treble
Adjust treble. –6dB – +6dB (0dB)
“Treble” can be set when the menu “Tone Control” setting is “On”.
