125
Audio
Setting items
Setting details
Audyssey DSX®
Provides more immersive
surround sound by adding
the new channels.
Wides/Heights : Turns on Audyssey DSX® processing for wide and
height expansion.
Wides : Turn on Audyssey DSX® processing for wide expansion.
Heights : Turn on Audyssey DSX® processing for height expansion.
Off : Do not set Audyssey DSX®.
NOTE
“Audyssey DSX®” cannot be configured if the HD Audio source being
played includes Front height and Front wide channels. In this case, the
respective channels are played back using the input signals.
Stage Width
Adjust sound stage width
when using front wide
speakers.
–10 – +10 (0)
Stage Height
Adjust sound stage height
when using front height
speakers.
–10 – +10 (0)
• “Audyssey DSX®” can be set when you are using front height speakers
or front wide speakers.
• “Audyssey DSX®” is only valid when using a center speaker.
• “Audyssey DSX®” is valid when surround mode is DOLBY listening
mode or DTS listening mode other than PL
gz Height.
About Audyssey Dynamic Surround Expansion (A-DSX)
Audyssey DSX® is a scalable system that adds new speakers to improve
surround impression. Starting with a 5.1 system Audyssey DSX® first
adds Wide channels for the biggest impact on envelopment. Research
in human hearing has proven that information from the Wide channels
is much more critical in the presentation of a realistic soundstage than
the Back Surround channels found in traditional 7.1 systems. Audyssey
DSX® then creates a pair of Height channels to reproduce the next
most important acoustical and perceptual cues. In addition to these
new Wide and Height channels, Audyssey DSX® applies Surround
Envelopment Processing to enhance the blend between the front and
surround channels.
Graphic EQ
Default settings are underlined.
Use the graphic equalizer to adjust the tone of each speaker.
“Graphic EQ” can be set when “MultEQ® XT 32” setting (
Setting items
Setting details
Speaker Selection
Select whether to adjust
tones for individual speakers
or for all speakers.
All : Adjust the tone of all speakers together.
Left/Right : Adjust the tone of left and right speakers together.
Each : Adjust the tone of each speaker.
Adjust EQ
Adjust tones for each
frequency band. Adjust
the speaker selected in
“Speaker Selection”.
q
Select the speaker.
w
Select the adjustment frequency band.
63Hz / 125Hz / 250Hz / 500Hz / 1kHz / 2kHz / 4kHz / 8kHz / 16kHz
• Select the speakers you want to adjust when “Left/Right” or “Each”
is selected.
e
Adjust the level.
–20.0dB – +6.0dB (0.0dB)
Curve Copy
Copy “Audyssey Flat”
(
) curve from
MultEQ® XT 32.
Yes : Copy.
No : Do not copy.
• “Curve Copy” is displayed after Audyssey® Setup has been performed.
• When you select “Curve Copy” and press
ENTER
, the “Copy “Audyssey
Flat”?” prompt is displayed. Select either “Yes” or “No”, and press
ENTER
.
Set Defaults
The “Graphic EQ” settings
are returned to the default
settings.
Reset : Reset to the defaults.
Cancel : Do not reset to the defaults.
When you select “Set Defaults” and press
ENTER
, the “Reset to the default values?”
prompt is displayed. Select either “Reset” or
“Cancel”, and press
ENTER
.
