Front panel
For buttons not explained here, see the page indicated in parentheses ( ).
u
t
y
r
q
w
e
q
STANDBY indicator ································································· (
GSTANDBY indicator statusH
• Power on : Off
• Normal standby : Red
• When “HDMI Pass Through” or “HDMI Control” (
is set to “On” : Orange
• When “Network” (
) is set to “Always On” : Orange
• When a mobile device that supports MHL is being charged :
Orange
w
Power operation button (
X ON/STANDBY) ························· (
Turns power to this unit on and off (standby).
r
VOLUME knob ································································· (
)
t
Remote control sensor ························································· (
)
y
Main display ··········································································· (
)
u
INPUT SELECTOR knob ·················································· (
)
e
Door
When you are using buttons and/or connectors behind the door,
press the bottom of the door to open it. When not using buttons
and/or connectors behind the door, close it. Be careful not to catch
your fingers when closing the door.
