Marantz AV8801 - Manual (Page 44)

41
Set up speakers (Audyssey® Setup)
n Subwoofer level error message and how to
adjust
The optimal level of each subwoofer channel for Audyssey Setup
measurement is 75 dB.
During subwoofer level measurement (
vpage 35 “Set up
speakers (Audyssey® Setup)”), an error message is displayed
when one level of subwoofers is outside the 72 – 78 dB range.
When using a subwoofer with built-in amplifier (active type), adjust
the subwoofer volume so that the subwoofer level is within the 72
to 78 dB range.
GError messageH
Audyssey Setup
Back SW Level Matching Skip
Your Subwoofer 1’s level is too high.
If your subwoofer has a volume control on it,
Select “SW Level Matching” to interactively adjust the level of
your subwoofer.
If your subwoofer does not have a volume control,
or if you do not want to use a subwoofer, select “Skip”.
1 Select “SW Level Matching” and
then press ENTER .
Subwoofer level measurement begins.
During measuring, a “Calibrating…”
message is displayed.
The measured level appears on the level
indicator after about 3 to 5 seconds.
Audyssey Setup
Next
60.0dB
Back
Calibrating...
Adjust the volume on your first subwoofer so that the level
below indicates 75dB
VOLUME
MIN MAX
Audyssey Setup
Next
--.-dB
Back
Calibrating...
Adjust the volume on your first subwoofer so that the level
below indicates 75dB
VOLUME
MIN MAX
Red
• If the measured level is outside the 72 to 78 dB range, the level
indicator is red.
• When measuring finishes, select “Back” and then press ENTER .
2 Adjust the volume control on your subwoofer so that
the measured level is within the 72 to 78 dB range.
Audyssey Setup
Next
75.0dB
Back
Calibrating...
Adjust the volume on your first subwoofer so that the level
below indicates 75dB
VOLUME
MIN MAX
Green
• If the measured level is within the 72 to 78 dB range, the level
indicator is green.
3 When the measured level is within the 72 to 78 dB
range, select “Next” and then press ENTER .
• If you use two subwoofers, the second subwoofer’s adjust will be
started.
Repeat the operation from step 2, 3.
When you use two subwoofers, adjust each subwoofer so that the
volume levels of Subwoofer 1 and Subwoofer 2 are appropriate for
your needs.
