4.5.2 DFNT Client 0 Status
Offset
Content
Description
4021
Client Cmd Request
This value is incremented each time a command request is
issued.
4022
Client Cmd Response This value is incremented each time a command response
is received.
4023
Client Cmd Error
This value is incremented each time an error message is
received from a remote unit or a local error is generated for
a command.
4024
Client Request Count This value is incremented each time a request message is
issued.
4025
Client Response
Count
This value is incremented each time a response message is
received.
4026
Client Error Sent
Count
This value is incremented each time an error is sent from
the client.
4027
Client Error Received
Count
This value is incremented each time an error is received
from a remote unit.
4028
Client Cfg Error Word This word contains a bit map that defines configuration
errors in the configuration file for the client.
4029
Client Current Error
Code
This value corresponds to the current error code for the
client.
4030
Client Last Error Code This value corresponds to the last error code recorded for
the client.
4.5.3 Block Status
Offset
Content
Description
4031
Read Block Count
This field contains the total number of read blocks
transferred from the module to the processor.
4032
Write Block Count
This field contains the total number of write blocks
transferred from the processor to the module.
4033
Parse Block Count
This field contains the total number of blocks successfully
parsed that were received from the processor.
4034
Command Event Block
Count
This field contains the total number of command event
blocks received from the processor.
4035
Command Block
Count
This field contains the total number of command blocks
received from the processor.
4036
Error Block Count
This field contains the total number of block errors
recognized by the module.
