Reference MVI46-DFNT ♦ SLC Platform
User Manual EtherNet/IP Client/Server Communication Module
Page 88 of 177 ProSoft Technology, Inc.
October 12, 2010
4.5.4 Pass-Through Server Status
Offset Content Description
4037 Socket State
4038 Connection State
4039 Open Count Total number of times the server has performed an open
operation.
4040 Establish Count Total number of times a connection has been established on
the server.
4041 Close Count Total number of times the server has performed a close
operation.
4042 Read Total number of packets received by the server.
4043 Message Total number of message receive by the server.
4044 Write Total number of packets sent from the server to the client.
4045 Timeout Total number of times the server as reached a connection
timeout condition.
4046 Host Port Service port on client connected to the server.
4047 to
4048
Host IP Address IP address of the client connected to the server.
4049 PTP Cfg Error Word Pass-through port configuration error word.
4050 PTS Cfg Error Word Pass-through server configuration error word.
The format of the client configuration error word is as follows:
Bit Description Value
0 0x0001
1 0x0002
2 0x0004
3 0x0008
4 Invalid retry count (0 to 10) 0x0010
5 0x0020
6 0x0040
7 0x0080
8 0x0100
9 0x0200
10 0x0400
11 0x0800
12 0x1000
13 0x2000
14 0x4000
15 0x8000
