Feature Avalon Address R/
W
Address CSR R Control Value
Field Range
Read valid
delay (3)
{id[3:0],
3'h2,lane_
addr[7:0],4'hC,
9'h00C}
{id[3:0],
3'h1,lane_
addr[7:0],
4'hC,9'h1A4}
Delay Value 6..0
Minimum Setting: 0
external clock cycles
Maximum Setting: 127
external memory clock
cycles
Incremental Delay: 1
external memory clock
cycle
Reserved 14..7
Enable 15
Reserved 31..16
Internal
VREF
Code
{id[3:0],
3'h2,lane_
addr[7:0],4'hC,
9'h014}
Not supported
VREF Code 5..0
Refer to Table 7 Reserved (5) 31..6 (5)
Where:
•
id[3:0]
refers to the Interface ID parameter
•
lane_addr[7:0]
refers to the address of a given lane in an interface. This is set by the Fitter and can be
queried in the parameter table as described in the Address Look-Up on page 25.
•
pin[4:0]
refers to the physical location of the pin in a lane. A pin location is either determined by the
Fitter or through a .qsf assignment and can be queried in the parameter table as described in the
Address Look-Up on page 25.
Note: For more information about calculating various clocking and delay calculations, depending on the
interface frequency and rate, refer to PHYLite_delay_calculations.xlsx .
Output and Strobe Enable Minimum and Maximum Phase Settings
When dynamically reconfiguring the interpolator phase settings, the values must be kept within the
ranges below to ensure proper operation of the circuitry.
Table 12: Output and Strobe Enable Minimum and Maximum Phase Settings
VCO Multiplication
Factor
Core Rate
Minimum Interpolator
Phase
Maximum Interpolator Phase
1
Full 0x100 0xA80
Half 0x280 0xBC0
Quarter 0x180 0xA00
(5) Reserved bit ranges must be zero
