Unit size 23 53 115
Temperature data
Temperature range approx. 15 °C / 27 °F
above room temperature up to
°C / °F 200 / 392 200 / 392 200 / 392
Temperature fluctuation ± K 0.1 0.1 0.1
Temperature uniformity
(variation) 1)
at 100 °C / 212°F ± K 1.5 2 3,5
at 200 °C / 392°F ± K 3 4.5 9
Heating up time 1) 2)
to 100 °C / 212°F min 65 80 95
to 200 °C / 392°F min 100 115 150
Max. temperature of inner chamber surfac-
es
°C / °F 320 / 608 320 / 608 320 / 608
Vacuum data
Vacuum connection with small flange
DN mm / inch 16 / 0.63 16 / 0.63 16 / 0.63
Measuring access port with small flange DN mm / inch 16 / 0.63 16 / 0.63 16 / 0.63
Inert gas connection with flow-limiter
Adapter with hose olive
∅ mm / inch 8 / 0.31 8 / 0.31 8 / 0.31
Permitted end vacuum
mbar / inHg 1x10 -2 /
0.0003
1x10 -2 /
0.0003
1x10 -2 /
0.0003
Leak rate
bar/h / inHg /h 1x10 -2 /
0.295
1x10 -2 /
0.295
1x10 -2 /
0.295
Classification of the explosion proof inner chamber
(according to ATEX Directive 94/9/EC) II -3G IIB T3-T1 Gc X
Electrical data
IP protection type according to EN 60529
IP 54 IP 54 IP 54
Nominal voltage (±10%) 50/60 Hz V 230 230 230
Nominal power kW 0.80 1.20 1.90
Unit fuse 5 x 20 mm / 250V /
middle-time-lag (M)
Amp 10 10 10
Power plug shock proof plug
Power plug vacuum module (option) shock proof plug
Energy consumption
at 100 °C / 212°F Wh/h 105 150 250
at 200 °C / 392°F Wh/h 280 445 785
Over-voltage category acc. to IEC 61010-1 II II II
Pollution degree acc. to IEC 61010-1 2 2 2
Legend:
1)
Values only in combination with aluminum racks
2) Time to reach 98% of the set point temperature
All technical data is specified for unloaded units with standard equipment at an ambient temperature of
+25 °C / 77 °F and a power supply voltage fluctuation of ±10. The temperature data is determined in ac-
cordance to BINDER factory standard following DIN 12880, observing the recommended wall clearances
of 10% of the height, width and depth of the inner chamber.
All indications are average values, typical for units produced in series. We reserve the right to
change technical specifications at any time.
