3
Model Parameters 4-ch 8-ch 16-ch
Video Bit Rate 1536Kbps-4096Kbps，
For 720P:default value is 2Mbps，max value is 4Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream Support
Audio Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate 64Kbps
Video Port Analog Video
Input
4-ch, BNC port 8-ch, BNC port 16-ch, BNC port
Network Video
Input
Switch 2 analog channels to the IP channels（8Mbps）
Video Output 1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same
video source)
Loop Output N/A
Matrix Output N/A
Audio Port Audio Input 4-ch，RCA port, audio via coaxial cable
Audio Output 1-ch，RCA port
Bidirectional
Talk Input
Support（Reuse the audio port）
Record Record Mode Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch playback Max 8-ch playback Max 16-ch
playback
Backup M ode HDD, burner, flash disk, network backup.
Alarm Alarm Input 4-ch alarm input 8-ch alarm input 16-ch alarm input
Alarm Output 3-ch alarm output
HDD HDD Port 2 SATA ports. Does not support eSATA port
Space/HDD 4T
Communication
Port
Network 1 RJ45 port, 1000Mbps Ethernet port
Communication RS485 port
USB 2 USB ports
Other Power DC12V
Power
Consumption
≤30W（exclude HDD）
Working
Temperature
-10℃－＋55℃
