10
Model Parameters 4-ch 8-ch
Working
Humidity
10%~90%
Dimension 1U case，375mm（W）×280mm（D）×50mm（H）
Weight 1.5-2.5kg（No HDD）
Installation
Mode
Desk installation
1.3.6 General 2-HDD 720P (V2) 1.5U Series
Model Parameters 4-ch 8-ch 16-ch
System Main Processor High-performance industrial embedded micro controller
OS Embedded LINUX
Video Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate 1536Kbps-4096Kbps，
For 720P:default value is 2Mbps，max value is 4Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream Support
Audio Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate 64Kbps
Video Port Analog Video
Input
4-ch, BNC port 8-ch, BNC port 16-ch, BNC port
Network Video
Input
Switch 2 analog channels to the IP channels（8Mbps）
Video Output 1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same
video source)
Loop Output N/A
Matrix Output N/A
Audio Port Audio Input 4-ch，RCA port, audio via coaxial cable
Audio Output 1-ch，RCA port
Bidirectional
Talk Input
Support（Reuse the audio port）
