69
Item Note
the video brightness if the value is high. But the video
noise may become too clear.
Color mode It includes several modes such as standard, color, bright,
gentle. Select a color mode, the sharpness, brightness,
contrast and etc can automatically switch to
corresponding setup.
EQ Click reset button, system can auto adjust the video to
the best effect.
This function is for analog channel only.
Image position It is to adjust the image position on the screen. The
value here refers to the pixel. The default pixel value is
16.
This function is for analog channel only.
4.4.4 Search
Please refer to chapter 4.8.1 for detailed infor mation.
4.4.5 Record Control
Please refer to chapter 4.10.4.3 for detailed infor mation.
4.4.6 Alarm Output
Please refer to chapter 4.10.3.4 for detailed infor mation.
4.4.7 Remote Device
Please refer to chapter 4.10.1.1 for detailed infor mation.
4.5 Navigation Bar
You need to go to the Main menu->Setting->System->General to enable navigation
bar function; other wise you can not see the following inter face.
The navigation bar is shown as below. See F igure 4-23.
Figure 4-23
4.5.1 Main Menu
Click button to go to the main menu interface.
4.5.2 Output Screen
Select corresponding windo w- split mode and output channels.
4.5.3 Favorites
