5
Model Parameters 4-ch 8-ch
Record Record Mode Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch playback Max 16-ch playback
Backup M ode HDD, burner, flash disk, network backup.
Alarm Alarm Input 4-ch alarm input 16-ch alarm input
Alarm Output 3-ch alarm output
HDD HDD Port 2 SATA ports. Does not support eSATA port.
Space/HDD 4T
Communication
Port
Network 1 RJ45 port, 1000Mbps Ethernet port
Communication RS485 port
USB 2 USB ports
Other Power DC12V
Power
Consumption
≤30W（exclude HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension 1U case，375mm（W）×280mm（D）×50mm（H）
Weight 1.5kg～2.5kg（exclude HDD）
Installation
Mode
Desk installation
1.3.3 Economic 720P (S2) 1U/ Special 16-ch Economic 720P（S2）1U
series
Model Parameters 4-ch Economic
720P (S2) 1U
8-ch Economic
720P (S2) 1U
16-ch
Economic
720P (S2) 1U
Special 16-ch
Economic 720P
（S2）1U
System Main Processor High-performance industrial embedded micro controller
OS Embedded LINUX
Video Video Encode
Standard
H.264
Encode
Resolution
720P(1-15fps)/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
HDCVI：1～15f/s（The 1
st
channel supports 25/30f/s）
CVBS：1~25f/s（PAL） ；1~30f/s（NTSC）
Video Bit Rate 1024Kbps-4096Kbps，
For 720P:default value is 1Mbps，max value is 4Mbps
For 960H:default value is 1Mbps，max value is 3Mbps
