134
 : Click it to delete a record type from one period.
 Record Type: Please check the box to select corresponding record type. There are
four types: Regular /MD ( motion detect)/Alar m/MD&Alar m.
 Week day: There are eight options: ranges from Saturday to Sunday and all.
 Holiday: It is to set holiday setup. Please note you need to go to the General interface
(Main Menu->System- >General) to add holiday first. Other wise you can not see this
item.
 Pre-record: System can pre-record the video before the event occurs into the file. The
value ranges from 1 to 30 seconds depending on the bit stream.
 Redundancy: System supports redundancy backup function. You can highlight
Redundancy button to activate this function. Please note, before enable this function,
please set at least one HDD as redundant. ( Main menu->Setting->Storage->HDD
Manager). Please note this function is null if there is only one HDD.
 Period setup: Click button after one date or a holiday, you can see an inter face
shown as in Figure 4-103.There are four record types: regular, motion detection ( MD),
Alar m, MD & alar m.
Please following the steps listed below to draw the period manually.
 Select a channel you want to set. See Figure 4-99.
Figure 4-99
 Set record type. See Figure 4-100.
Figure 4-100
 Please draw manually to set record period. There are six periods in one day. See
Figure 4-101.
