106
 Network type: There are various network types for different 3G network modules. You
can select according to your requirements.
 APN: It is the wireless connection server. It is to set you access the wireless network
via which method.
 AUTH: It is the authentication mode. It supports PAP/CHAP.
 Dial number: Please input 3G network dialup number you got from your ISP.
 User name: It is the user name for you to login the 3G network.
 Password: It is the password for you to login the 3G network.
 Pulse interval: You can set dialup duration. Once you disable the extra stream, the
connection time begins. For example, if you input 5 seconds here, then 3G network
connection period is 5 seconds. The device automatically disconnect when time is up.
If there is no extra stream, 3G network connection is valid all the time. If the alive
time is 0, then the 3G network connection is valid all the time.
 Dial: Here you can enable or disable 3G network connection/disconnection manually.
 3G wireless network: Here is to display wireless network status, SIM card status, dial
status. If the 3G connection is OK, then you can see the device IP address the
wireless network automatically allocates.
Figure 4-65
4.10.2.5 PPPoE
PPPoE interface is shown as in Figure 4-66.
Input “PPPoE name” and “PPPoE password” you get from your ISP (Internet service
provider).
Click save button, you need to restart to activate your configuration.
1
2
3
