185
Pulse interval It is to set time to end 3G connection after you close extra
stream monitor. For example, if you input 60 here, system ends
3G connection after you close extra stream monitor 60 seconds.
Important
 If the pulse interval is 0, then system does not end 3G connection after
you close the extra stream monitor.
 Pulse interval here is for extra stream only. This item is null if you are
using main stream to monitor.
5.8.2.5.2 Mobile
The mobile setup interface is shown as in Figure 5-30.
Here you can activate or turn off the 3G connected phone or mobile phone, or the phone
you set to get alarm message.
Figure 5-30
5.8.2.6 PPPoE
The PPPoE interface is shown as in Figure 5-31.
Input the PPPoE user name and password you get from the IPS (internet service provider)
and enable PPPoE function. Please save current setup and then reboot the device to get
the setup activated.
Device connects to the internet via PPPoE after reboot. You can get the IP address in the
WAN from the IP address column.
Please note, you need to use previous IP address in the LAN to login the device.
Please go to the IP address item to via the device current device information. You
can access the client-end via this new address.
Figure 5-31
