RIGOL Chapter 5 Specifications
5-6 DG1000Z User’s Guide
Pulse Width >60ns (typical)
Maximum Frequency 1MHz
Clock Reference
Phase Offset
Range
0° to 360°
Resolution 0.03°
External Reference Input
Lock Range
10MHz±50Hz
Level 250mVpp to 5Vpp
Lock Time <2s
Impedance (typical) 1kΩ, AC coupling
Internal Reference Output
Frequency
10MHz±50Hz
Level 3.3Vpp
Impedance (typical) 50Ω, AC coupling
Sync Output
Level
TTL-compatible
Impedance 50Ω, nominal value
Overvoltage Protection
Overvoltage protection will take effect once any of the following two conditions is
met:
 The amplitude setting in the generator is greater than 2Vpp or the output
offset is greater than |2V
DC
|, the input voltage is greater than
±11.5×(1±5%)V (<10kHz).
 The amplitude setting in the generator is lower than or equal to 2Vpp or the
output offset is lower than or equal to |2V
DC
|, the input voltage is greater than
±3.5×(1±5%)V (<10kHz).
General Specifications
Power
Power Voltage
100V to 240V (45Hz to 440Hz)
Power Consumption Less than 40W
Fuse 250V, T3.15A
Display
Type
3-inch TFT LCD
Resolution 320 Horizontal×RGB×240 Vertical Resolution
Color 16M color
Environment
Temperature Range
Operating: 0℃ to 50℃
Non-Operating: -40℃ to 70℃
Cooling Method Cooling by fans compulsively
