Chapter 2 Front Panel Operations RIGOL
DG1000Z User’s Guide 2-25
Volatile Waveform
Press Arb  Select Wform  Volatile Wform to select arbitrary waveform
currently stored in the volatile memory. If there is no waveform data in volatile
memory currently, this menu would be unavailable. At this time, you can fill up the
volatile memory through the methods below.
1. Fill up the volatile memory with the waveform currently edited through Edit
Wform.
2. Press Arb  Edit Wform  Data Src to select “CH1 Arb”、”CH2 Arb” or “Vol”.
Then copy the currently selected arbitrary waveform of CH1 or CH2 or the
waveform of the other channel’s volatile memory to the volatile memory of the
currently selected channel.
When “Volatile Wform” is selected, users can edit the volatile waveform using the
Edit Wform menu. The new waveform data will overwrite the previous data in the
volatile memory. You can also save the new volatile waveform in non-volatile
memory.
