4-6 P/N 480-0062-00-10
Chapter 4: Advanced Topic: View Call Detail Records
Tenor AX Establishes Connection with CDR Server
To capture CDR reports via CDR server (i.e., a PC or workstation you use to capture CDR data) you
must first configure the IP address and port number of the CDR server in the Tenor AX unit. Once
these are configured, the Tenor AX unit will be able to establish a TCP/IP session with the server on
its own.
CDR Server Establishes Connection with Tenor AX
If no IP address/port number is configured, the CDR server has to initiate the session. The Tenor AX
unit uses TCP port numbers 9002 and 9003 on its side for the CDR sessions. The CDRServerport
must still be configured to either 9002 or 9003 (see the Command Line Interface User Guide for
specific information).
Whether the Tenor AX unit establishes the connection with the CDR server or the CDR server
attempts to establish the connection, there is a limit of 5 attempts to enter the correct password
before the TCP session is terminated (to configure a password, see the CLI command cdrpassword
in the previous section).
After the CDR server successfully logs into the CDR port of the Tenor AX unit, the CDR server will
be provided with the IP address and unit name of the Tenor AX. The CDR server will then supply the
sequence number of the last CDR that it has received from the Tenor AX unit. If the last CDR num-
ber is unknown, the server should send 0 for the sequence number. After this exchange, the Tenor
AX will start delivering new CDRs to the server.
