2. On the Design tab, type a new trap map name.
3. Select a mapping type.
4. Do one of the following:
• In the MIB pane of SNMP Driver Creator, drag a trap node to the Trap OID area of the
Create Trap Map window.
Figure 8-64
OR,
Perform the following sub-procedure in the Trap OID area of the Create Trap Map window.
a) Click Add.
A highlighted, unconfigured trap OID row appears.
Figure 8-65
b) In the row corresponding to the new trap OID, click or double-click the cells in each
column to enter the required data.
5. Do one of the following:
Note: Depending on which cell you click, either select from one of the listed
options or type the desired value to configure the parameter.
